AMEREX
offers a full line of standard stainless steel structural
shapes.
 |
 |
 |
 |
| TEES |
ANGLES |
CHANNELS |
I-BEAMS |
| Designers
prefer the extruded structural shape over its rolled counterpart
for several reasons: |
|
Faster
Delivery -
|
the
nature of the extrusion process makes small runs economically
feasible and short lead time possible. |
|
Leg
Uniformity -
|
leg
lengths are generally more uniform in the extruded product.
|
|
Superior
Straightness -
|
since
all extrusions are stretch-straightened, they are usually straighter
than the rolled product. |
|
Tighter
Tolerances -
|
closer
dimensional accuracy, particularly on leg lengths, provide better
fit-ups. |
SPECIFICATIONS
The following specifications can be applied to structural products: |
| ASTM
A276 |
ASTM
A479 |
ASME
SA479 |
QQS-763 |
| AISC
tolerances apply to structurals 3" and over. |
| All
items shall be furnished in the as extruded, annealed and pickled
and cold stretch straightened condition with a 250 RMS or better
finish. |
SHIPPING
TOLERANCES
|
10,000#
and over
|
+/-
5% |
|
9,999#
- 5,000#
|
+/-
10%
|
|
4,999#
- 2,000#
|
+/-
20% |
|
GRADES
Other
grades/specifications available upon request.
Dimensions and minimum weight/foot may change. Please inquire
mill for specifics. |
|
